Note: Travel optional: 50MM 100MM 150MM 200MM 300MM 400MM 500MM
Please consult customer service for other itinerary prices
Product parameters:
| Product model | PT-SD140-50XY | PT-SD140-100XY | PT-SD140-150XY | PT-SD140-200XY | PT-SD140-300XY | PT-SD140-400XY | PT-SD140-500XY | |
| Structural parameter | Journey | 50mm | 100mm | 150mm | 200mm | 300mm | 400mm | 500mm |
| Table size | 148×148mm | 148×148mm | 148×148mm | 148×148mm | 148×148mm | 148×148mm | 148×148mm | |
| Screw specification | Precision ball screw (lead 4mm) | Ball screw (lead 5mm) | ||||||
| Rail | Precision linear slider guide | |||||||
| Stepper motor | 42（1.8°） | 57（1.8°） | ||||||
| Bulk material | Aluminium alloy | |||||||
| Surface treatment | Anodized black | |||||||
| Mesa center load | 30kg | 50kg | ||||||
| Dead weight of platform | 2.8kg | 3.4kg | 4.5kg | 5.2kg | 6.3kg | 7.2kg | 8.3kg | |
| Precision parameter | 8 Subdivision resolution | —— | 3.125um | |||||
| speed | 20mm/sec | —— | 50mm/sec | |||||
| Repeated positioning accuracy | 5um | |||||||
| Positioning accuracy (optional grating parameters) | 8um | |||||||
| straightness | 5um | 6um | 8um | |||||
| Parallelism of motion | 10um | 15um | 20um | |||||
| Tilt | 25'' | 50'' | 60'' | |||||
| runout | 20'' | 25'' | 30'' | |||||
| Return clearance | 2um | |||||||
| Attachment description | Can be equipped with loss of power braking function（Z） | |||||||
| Grating ruler can be added（G） | ||||||||
| Replaceable servo motor（D） | ||||||||
Product size:
We can ship to you by UPS,FEDEX,DHL,TNT,EMS,other shipping terms can also be arranged according to specific requirements.
We can ship to you by UPS,FEDEX,DHL,TNT,EMS,other shipping terms can also be arranged according to specific requirements.
Note:
We are glad that you can cooperate with us.,As the journey is far away, please be sure to see the parameters or communicate with our sales when selecting the product, Avoid buying wrong products to delay your use.
