亮 / 暗视场观察用 BD Plan Apo
货号 | Mag. | N.A. | W.D. | f | R | D.F. | 视场 1 | 视场 2 | 重量 |
378-831-5 | 2X | 0.055 | 34.0mm | 100mm | 5.0µm | 91µm | ø12mm | 42.4x3.2mm | 230g |
378-832-6 | 5X | 0.14 | 34.0mm | 40mm | 2.0µm | 14.0µm | ø4.8mm | 0.96x1.28mm | 240g |
378-833-5 | 10X | 0.28 | 33.5mm | 20mm | 1.0µm | 3.5µm | ø2.4mm | 0.48x0.64mm | 240g |
378-788-5 | 20X | 0.42 | 20.0mm | 10mm | 0.7µm | 0.7µm | ø1.2mm | 0.24x0.32mm | 300g |
378-835-5 | 50X | 0.55 | 13.0mm | 4mm | 0.5µm | 0.9µm | ø0.48mm | 0.10x0.13mm | 320g |
378-836-5 | 100X | 0.70 | 6.0mm | 2mm | 0.4µm | 0.6µm | ø0.24mm | 0.05x0.06mm | 320g |
亮 / 暗视场观察 BD Plan Apo SL
货号 | Mag. | N.A. | W.D. | f | R | D.F. | 视场 1 | 视场 2 | 重量 |
378-840-5 | 20X | 0.28 | 30.5mm | 10mm | 1.0µm | 3.5µm | ø1.2mm | 0.24x0.32mm | 240g |
378-841-5 | 50X | 0.42 | 20.0mm | 4mm | 0.7µm | 1.6µm | ø0.48mm | 0.10x0.13mm | 310g |
378-842-5 | 80X | 0.50 | 15.0mm | 2mm | 0.6µm | 1.1µm | ø0.3mm | 0.48x0.64mm | 320g |
378-843-5 | 100X | 0.55 | 13.0mm | 2mm | 0.5µm | 0.9µm | ø0.24mm | 0.05x0.06mm | 320g |
注：
这些物镜具有超长工作距离
Mag.: 倍率
N.A.: 数值孔径
W.D.: 工作距离
f: 焦距
R: 分辨能力
D.F.: 景深
视场 1: 当使用 ø24mm 的目镜时的视场
视场 2: 当使用 1/2" CCD 相机时的视场
PDV has many different motorized linear translation stage including motorized translation stage, motorized linear stage, High Precision Motorized Goniometer Stages High Precision Motorized XY Stages、 High quality China Motorized Linear Stage. They can be any combination, building block structure, can satisfy any scene usage requirement.
It is used for the fixation and adjustment of objective lens and lens.Meet the requirements of your experimental scenario.
We are glad that you can cooperate with us.,As the journey is far away, please be sure to see the parameters or communicate with our sales when selecting the product, Avoid buying wrong products to delay your use..
