Introduction To Various Types Of Functional Of The Motorized Rotation Stage

The Motorized Rotation Stage is a revolutionary new product. It is used in a variety of rotary motion applications. It combines high work efficiency, high precision, high rigidity and high cost performance. It is a revolutionary product in the rotary motion mechanism. It can satisfy the segmentation. The digital control can not be achieved, and the positioning accuracy is comparable to that of the DD motor. It can greatly reduce the cost and bring you unexpected results!

The Rotation Stage is a blank on the market. The hollow rotary platform is a digital positioning rotary platform with high positioning accuracy. It has the advantages of low cost and high precision, and it occupies a strong market in the rotary platform category.

Introduction to various types of functional structures of the rotary table

The worm-gear rotary table can provide a large transmission ratio, and the structure is relatively compact. The meshing between the worm and the worm wheel is gradually entered and gradually withdrawn, so the impact load is small, the rotation is smooth, the load capacity is large, and the precision is high. The transmission efficiency is low, the friction is large, and when the transmission is relatively large, it is not suitable for high-speed rotation.

Timing belt rotary table:

Synchronous belt-driven rotary table, the speed is faster, but because the transmission is relatively small, it is not suitable for large load rotation, and the timing belt has a certain amount of expansion and contraction, which is not suitable for precise positioning. Gear Rotation Stages Gear-driven rotary table It has the characteristics of high efficiency, compact structure and stable transmission ratio, but it is prone to tooth surface wear, broken teeth and excessive gear teeth. To prevent this, it is usually necessary to leave a certain gap. This gap is also used to prevent Due to the error and thermal deformation, the gear is stuck, and there is space for the lubricating oil film between the tooth surfaces, but the gap makes the airwheel in the reverse direction and cannot be accurately positioned.
