A long working distance objective with an infinite conjugated parfocal distance of 95mm
The color difference of visible spectral region is corrected, and the machining surface can be observed coaxial with the laser beam
Can be used for 355nm, 532nm laser processing
Good imaging performance at 365nm and 405nm
specification:
| product name | Article number | Numerical aperture | Working distance | Focal length | Resolution | Focal depth | Objective feld number（mm） | weight | |
| NA | WD（mm） | f(mm) | R（um） | ±D.F（um) | ø24eyepiece | 1”camera | （g） | ||
| M Plan Apo NUV 20X | 0310-9020-2000 | 0.42 | 17 | 10 | 0.65 | 1.56 | 1.2 | 0.48×0.64 | 268 |
| M Plan Apo HR NUV 50X | 0310-9050-2001 | 0.65 | 10 | 4 | 0.42 | 0.65 | 0.48 | 0.19×0.26 | 405 |
* Resolution and objective focal depth are calculated based on the reference wavelength λ=550nm
Product details:Exterior dimensional drawing:
